How to Use GPU With TensorFlow For Faster Training?

12 minutes read

To use GPU with TensorFlow for faster training, you need to follow the following steps:

  1. Install necessary components: Install CUDA Toolkit: TensorFlow requires CUDA to utilize the GPU. Install the appropriate version of CUDA Toolkit from the NVIDIA Developer website. Install cuDNN: TensorFlow also needs cuDNN (CUDA Deep Neural Network library) for accelerated GPU training. Download and install cuDNN from the NVIDIA Developer website, making sure to match the version with your installed CUDA Toolkit. Install TensorFlow: Install TensorFlow on your system using pip or conda, depending on your preference and environment.
  2. Check GPU availability: Open a Python shell or Jupyter Notebook. Import TensorFlow by running import tensorflow as tf. Run print(tf.config.list_physical_devices('GPU')) to check if your GPU is recognized. If it returns an empty list, ensure that the GPU drivers and libraries are correctly installed.
  3. Enable GPU memory growth: TensorFlow allocates GPU memory by default, which can cause memory errors. To enable dynamic allocation of GPU memory, use the following code snippet: physical_devices = tf.config.list_physical_devices('GPU') try: tf.config.experimental.set_memory_growth(physical_devices[0], True) except: # Invalid device or cannot modify virtual devices once initialized. pass
  4. Utilize the GPU during training: To move your TensorFlow computations to the GPU, you typically define and train your models within a tf.distribute.Strategy scope. For example: strategy = tf.distribute.OneDeviceStrategy("GPU:0") # Utilize a single GPU with strategy.scope(): model = create_model() model.compile(optimizer='adam', loss='sparse_categorical_crossentropy', ...) model.fit(train_dataset, epochs=10, ...)
  5. Verify GPU utilization: While training, monitor the GPU utilization to ensure it's being effectively utilized. You can use tools like nvidia-smi or nvtop on the command line to check GPU usage, memory, and other details.


By following these steps, you can effectively use the GPU for accelerating TensorFlow model training and enjoy faster results.

Best TensorFlow Books to Read in 2024

1
Machine Learning Using TensorFlow Cookbook: Create powerful machine learning algorithms with TensorFlow

Rating is 5 out of 5

Machine Learning Using TensorFlow Cookbook: Create powerful machine learning algorithms with TensorFlow

2
Learning TensorFlow: A Guide to Building Deep Learning Systems

Rating is 4.9 out of 5

Learning TensorFlow: A Guide to Building Deep Learning Systems

3
Generative AI with Python and TensorFlow 2: Create images, text, and music with VAEs, GANs, LSTMs, Transformer models

Rating is 4.8 out of 5

Generative AI with Python and TensorFlow 2: Create images, text, and music with VAEs, GANs, LSTMs, Transformer models

4
TensorFlow in Action

Rating is 4.7 out of 5

TensorFlow in Action

5
Learning TensorFlow.js: Powerful Machine Learning in JavaScript

Rating is 4.6 out of 5

Learning TensorFlow.js: Powerful Machine Learning in JavaScript

6
TinyML: Machine Learning with TensorFlow Lite on Arduino and Ultra-Low-Power Microcontrollers

Rating is 4.5 out of 5

TinyML: Machine Learning with TensorFlow Lite on Arduino and Ultra-Low-Power Microcontrollers

7
Deep Learning with TensorFlow 2 and Keras: Regression, ConvNets, GANs, RNNs, NLP, and more with TensorFlow 2 and the Keras API, 2nd Edition

Rating is 4.4 out of 5

Deep Learning with TensorFlow 2 and Keras: Regression, ConvNets, GANs, RNNs, NLP, and more with TensorFlow 2 and the Keras API, 2nd Edition

8
Machine Learning with TensorFlow, Second Edition

Rating is 4.3 out of 5

Machine Learning with TensorFlow, Second Edition

9
TensorFlow for Deep Learning: From Linear Regression to Reinforcement Learning

Rating is 4.2 out of 5

TensorFlow for Deep Learning: From Linear Regression to Reinforcement Learning

10
Hands-On Machine Learning with Scikit-Learn and TensorFlow: Concepts, Tools, and Techniques to Build Intelligent Systems

Rating is 4.1 out of 5

Hands-On Machine Learning with Scikit-Learn and TensorFlow: Concepts, Tools, and Techniques to Build Intelligent Systems


What is CUDA and why is it important for TensorFlow GPU usage?

CUDA (Compute Unified Device Architecture) is a parallel computing platform and API model created by NVIDIA. It enables developers to harness the computational power of NVIDIA GPUs to accelerate a wide range of computing tasks.


TensorFlow is an open-source machine learning framework that supports both CPU and GPU computations. However, leveraging GPUs for TensorFlow computations requires CUDA. CUDA provides the programming interface and runtime system for GPU acceleration in TensorFlow. It allows TensorFlow to execute operations on the GPU, enabling significant speedups in deep learning training and inference compared to running on traditional CPUs.


CUDA provides a set of libraries, compiler directives, and tools that enable developers to write GPU-accelerated code using familiar programming languages like C++, Python, and others. It optimizes memory management, data transfer, and parallel execution on the GPU, leading to efficient and high-performance computations.


In summary, CUDA is crucial for TensorFlow GPU usage as it enables the framework to utilize the computational power of NVIDIA GPUs, resulting in faster deep learning computations and improved training and inference times.


How to profile TensorFlow GPU performance using NVPROF?

Profiling TensorFlow GPU performance using NVPROF can be done by following these steps:

  1. Install the latest NVIDIA drivers and CUDA toolkit on your system.
  2. Install the NVPROF command-line profiler, which comes bundled with the CUDA toolkit.
  3. Launch the TensorFlow script you want to profile. Make sure to enable GPU support, either by setting the CUDA_VISIBLE_DEVICES environment variable or by using the tf.config.experimental.set_visible_devices API.
  4. Open a terminal and navigate to the directory where your TensorFlow script is located.
  5. Run NVPROF with the --profile-from-start off flag to disable the initial profiling: nvprof --profile-from-start off -o profile.nvvp python your_script.py
  6. Let your TensorFlow script run for a sufficient period to capture meaningful profiling data. You can adjust the duration by modifying the script or using a smaller test dataset.
  7. After your script finishes running, NVPROF will generate a profile.nvvp file containing the profiling results.
  8. Open NVVP (NVIDIA Visual Profiler) by executing nvvp in the terminal.
  9. In NVVP, go to "File" > "Open," and select the profile.nvvp file generated in step 7.
  10. NVVP will load the profiling data and provide various performance analysis tools. You can explore different visualizations, such as the timeline, metrics, and memory usage, to gain insights into TensorFlow GPU performance.
  11. Analyze the profiling results to identify potential bottlenecks or areas for optimization. Pay attention to GPU utilization, memory transfers, kernel execution times, and other relevant metrics.
  12. Make improvements to your TensorFlow script based on the profiling insights you gained. Consider optimizing operations, reducing unnecessary memory transfers, batch processing, or using TensorFlow's performance-tuning techniques.
  13. Repeat the profiling process as needed to track the impact of your optimizations and continue fine-tuning your TensorFlow GPU performance.


Remember, optimizing GPU performance in TensorFlow might involve a combination of techniques, such as optimizing algorithms, utilizing GPU-specific optimizations (e.g., CUDA kernels), and adjusting TensorFlow configuration parameters.


How to monitor GPU usage during TensorFlow training?

There are different ways to monitor GPU usage during TensorFlow training. Here are a few common methods:

  1. NVIDIA System Management Interface (nvidia-smi): If you have an NVIDIA GPU, you can use the command-line tool nvidia-smi to monitor GPU usage. Open a terminal and run the command "nvidia-smi" while your TensorFlow training is running. It will show you real-time GPU utilization, memory usage, temperature, and other information.
  2. TensorBoard: TensorBoard is a web-based visualization tool that comes with TensorFlow. You can integrate it into your code to monitor GPU usage during training. It provides a variety of metrics and summaries that you can log and display, including GPU utilization. You can log GPU usage by using the TensorFlow's "tf.summary.gpu_utilization()" function.
  3. profiler.Profiler: TensorFlow's Profiler provides low-level profiling support for GPU usage. You can use it to collect GPU timeline information, including GPU utilization, memory usage, and kernel execution time. With the profiler, you can analyze the performance of your TensorFlow training at a granular level. To use the profiler, you need to enable it in your TensorFlow code and then run your training script with the profiler enabled.
  4. Third-party monitoring tools: Various third-party monitoring tools are available for GPU monitoring, such as NVIDIA Data Center GPU Manager (DCGM) and GPU-Z. These tools can provide more detailed GPU usage information, including temperature, power consumption, and clock speeds. You can run these tools alongside your TensorFlow training to monitor GPU usage.


Remember to periodically check the GPU usage to ensure that it is being fully utilized and to identify any bottlenecks that may affect the training performance.
