How to Define A Function In MATLAB?

10 minutes read

To define a function in MATLAB, you can follow these steps:

  1. Open a new script file or navigate to an existing one in the MATLAB editor.
  2. Begin the function definition by typing the keyword "function" followed by the output variable(s) inside square brackets, then the function name and input variable(s) inside parentheses. For example: function output = functionName(input1, input2)
  3. Add a comment line (optional) to describe what the function does.
  4. Start the function body by writing the code that carries out the desired computations or operations.
  5. Use the "output" variable to store the result(s) of the function's calculations.
  6. End the function by adding the keyword "end" on a new line.
  7. Save the script file with a meaningful name, typically matching the function name.


Here is a simple example of a function that calculates the sum of two numbers:

1
2
3
4
5
6
function output = sumNumbers(a, b)
    % This function calculates the sum of two numbers

    output = a + b;  % Compute the sum

end


Once you have defined the function in a script file, you can call it from the command window or other scripts by using its name followed by the inputs in parentheses, and assigning the output value to a variable if needed:

1
2
result = sumNumbers(5, 7);  % Calling the function and storing the output in 'result'
disp(result);  % Display the result in the command window


This is a basic overview of how to define and use functions in MATLAB. Functions can have multiple inputs and outputs, and their code can be as simple or complex as needed.

Best Matlab Books to Read in 2024

1
MATLAB: An Introduction with Applications

Rating is 5 out of 5

MATLAB: An Introduction with Applications

2
MATLAB and Simulink In-Depth: Model-based Design with Simulink and Stateflow, User Interface, Scripting, Simulation, Visualization and Debugging

Rating is 4.9 out of 5

MATLAB and Simulink In-Depth: Model-based Design with Simulink and Stateflow, User Interface, Scripting, Simulation, Visualization and Debugging

3
Matlab: A Practical Introduction to Programming and Problem Solving

Rating is 4.8 out of 5

Matlab: A Practical Introduction to Programming and Problem Solving

4
MATLAB for Engineers

Rating is 4.7 out of 5

MATLAB for Engineers

5
Matlab: A Practical Introduction to Programming and Problem Solving

Rating is 4.6 out of 5

Matlab: A Practical Introduction to Programming and Problem Solving

6
MATLAB: A Practical Introduction to Programming and Problem Solving

Rating is 4.5 out of 5

MATLAB: A Practical Introduction to Programming and Problem Solving

7
MATLAB: An Introduction with Applications

Rating is 4.4 out of 5

MATLAB: An Introduction with Applications

8
MATLAB for Engineers (4th Edition)

Rating is 4.3 out of 5

MATLAB for Engineers (4th Edition)


What are anonymous functions in MATLAB and how to create them?

Anonymous functions in MATLAB are a type of function that does not have a name. These functions are defined inline and do not require a separate file. Anonymous functions are useful for creating simple functions on-the-fly without the need to define a separate function file.


To create an anonymous function in MATLAB, you can use the following syntax:

1
function_handle = @(input_parameters) expression


Here, function_handle is a variable that stores the anonymous function, input_parameters are the input arguments to the function, and expression is the expression that defines the function's behavior.


For example, to create an anonymous function that squares a given input value, you can do the following:

1
square = @(x) x^2;


In this case, square is the handle to the anonymous function, and x is the input parameter. The expression x^2 calculates the square of the input value.


You can then use the anonymous function just like any other function in MATLAB. For example, to square a value, you can call the square function like this:

1
result = square(5);


The variable result will be assigned the value 25 in this case.


What is a local variable in MATLAB functions?

A local variable in MATLAB functions is a variable that is defined within the scope of a function and can only be accessed and used within that function. It is not visible or accessible outside the function. Local variables are useful for storing intermediate results or temporary values that are only needed within the function's execution.


What are nested functions in MATLAB?

Nested functions in MATLAB refer to the practice of defining a function within another function. In other words, a function is enclosed within another function. These nested functions can access and use variables from the outer main function, allowing for a more organized and modular code structure.


Nested functions are useful when a specific functionality needs to be implemented repeatedly within the main function, but it is not required by other functions outside the main function. By encapsulating this repeated functionality within a nested function, the main function becomes more focused and easier to read and understand.


Here is an example demonstrating nested functions in MATLAB:

1
2
3
4
5
6
7
8
function mainFunction(x)
    y = nestedFunction(x); % calling the nested function within the main function
    disp(y);

    function nestedOutput = nestedFunction(input)
        nestedOutput = input * 2; % performing a specific task
    end
end


In the above example, nestedFunction is defined within mainFunction. The main function accepts an input x, calls the nested function with x and displays the output y. The nested function simply doubles the input value.


How to add comments/documentation to a MATLAB function?

To add comments/documentation to a MATLAB function, you can use the following guidelines:

  1. Function Signature: Start by providing a brief description of the function right under the function signature line. Explain the purpose, inputs, and outputs of the function.
1
2
3
4
5
6
7
8
% This function performs a specific task
% Inputs:
%   arg1: description of arg1
%   arg2: description of arg2
% Outputs:
%   out1: description of out1
%   out2: description of out2
function [out1, out2] = functionName(arg1, arg2)


  1. Comment Blocks: Use comment blocks (%{...%}) to explain the overall logic and main steps of the function.
1
2
3
4
5
6
%{
    Description: The function performs a specific task by following these steps:
        1. Step 1 explanation.
        2. Step 2 explanation.
        ...
%}


  1. Inline Comments: Use inline comments (%) throughout your code to describe specific lines or sections of the function.
1
2
% This line converts the input to double
input = double(input);


  1. Variable Descriptions: Add comments before variable assignments to describe their purpose.
1
2
% Initialize the counter variable
counter = 0;


  1. Sections/Subsections: Divide your code into sections or subsections, and provide a comment at the beginning of each section to describe its purpose.
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
%% Section 1: Data Preparation
%{
    Description: This section preprocesses the data by performing the following steps:
        1. Step 1 explanation.
        2. Step 2 explanation.
        ...
%}

%% Section 2: Data Analysis
%{
    Description: This section analyzes the data by performing the following steps:
        1. Step 1 explanation.
        2. Step 2 explanation.
        ...
%}


  1. Examples: Include examples at the end of your function to demonstrate how to use it.
1
2
3
4
5
% Example usage:
%{
    input = [1, 2, 3, 4];
    output = functionName(input);
%}


By incorporating these guidelines, you can create clear and comprehensive comments/documentation that will help you and others understand and use your MATLAB functions effectively.
