How to Show Multiple Charts In Matplotlib

8 minutes read

To show multiple charts in Matplotlib, you can use the subplot() function to create a grid of subplots within a single figure. This function takes three arguments: the number of rows, the number of columns, and the index of the subplot you want to create.


For example, if you want to create a 2x2 grid of subplots, you can use the following code:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
plt.subplot(2, 2, 1)
plt.plot(x1, y1)

plt.subplot(2, 2, 2)
plt.plot(x2, y2)

plt.subplot(2, 2, 3)
plt.plot(x3, y3)

plt.subplot(2, 2, 4)
plt.plot(x4, y4)

plt.show()


This code will create a 2x2 grid of subplots with a different chart in each subplot. You can customize the size and layout of the subplots by adjusting the arguments passed to the subplot() function.

Best Python Books to Read in 2024

1
Learning Python, 5th Edition

Rating is 5 out of 5

Learning Python, 5th Edition

2
Python Programming and SQL: [7 in 1] The Most Comprehensive Coding Course from Beginners to Advanced | Master Python & SQL in Record Time with Insider Tips and Expert Secrets

Rating is 4.9 out of 5

Python Programming and SQL: [7 in 1] The Most Comprehensive Coding Course from Beginners to Advanced | Master Python & SQL in Record Time with Insider Tips and Expert Secrets

3
Introducing Python: Modern Computing in Simple Packages

Rating is 4.8 out of 5

Introducing Python: Modern Computing in Simple Packages

4
Python for Data Analysis: Data Wrangling with pandas, NumPy, and Jupyter

Rating is 4.7 out of 5

Python for Data Analysis: Data Wrangling with pandas, NumPy, and Jupyter

5
Python Programming for Beginners: Ultimate Crash Course From Zero to Hero in Just One Week!

Rating is 4.6 out of 5

Python Programming for Beginners: Ultimate Crash Course From Zero to Hero in Just One Week!

6
Python All-in-One For Dummies (For Dummies (Computer/Tech))

Rating is 4.5 out of 5

Python All-in-One For Dummies (For Dummies (Computer/Tech))

7
Python Crash Course, 3rd Edition: A Hands-On, Project-Based Introduction to Programming

Rating is 4.4 out of 5

Python Crash Course, 3rd Edition: A Hands-On, Project-Based Introduction to Programming

8
Python Programming for Beginners: The Complete Guide to Mastering Python in 7 Days with Hands-On Exercises – Top Secret Coding Tips to Get an Unfair Advantage and Land Your Dream Job!

Rating is 4.3 out of 5

Python Programming for Beginners: The Complete Guide to Mastering Python in 7 Days with Hands-On Exercises – Top Secret Coding Tips to Get an Unfair Advantage and Land Your Dream Job!


How to share axes between multiple charts in matplotlib?

To share axes between multiple charts in matplotlib, you can use the sharex and sharey parameters when creating the subplots. Here's an example:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
import matplotlib.pyplot as plt

# Create the first subplot
fig, axs = plt.subplots(2, 1, sharex=True, sharey=True)
ax1 = axs[0]
ax2 = axs[1]

# Plot on the first subplot
ax1.plot([1, 2, 3], [4, 5, 6])

# Plot on the second subplot
ax2.plot([1, 2, 3], [6, 5, 4])

plt.show()


In this example, we create two subplots with the sharex=True and sharey=True parameters, which makes the x-axis and y-axis shared between the two subplots. This ensures that the axes of the two subplots are synchronized and have the same scale.


How to plot multiple charts with shared x-axis in matplotlib?

You can plot multiple charts with a shared x-axis in matplotlib by using the subplots() function to create a figure with multiple axes, and then specifying sharex=True when creating the axes. This will ensure that all the subplots share the same x-axis.


Here is an example code snippet:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
import matplotlib.pyplot as plt

# Create a figure and a set of subplots
fig, axs = plt.subplots(2, 1, sharex=True)

# Plot data on the first subplot
axs[0].plot([1, 2, 3, 4], [10, 20, 15, 25])
axs[0].set_title('First Subplot')

# Plot data on the second subplot
axs[1].plot([1, 2, 3, 4], [5, 10, 15, 20])
axs[1].set_title('Second Subplot')

# Set common x-axis label
fig.text(0.5, 0.04, 'X-axis', ha='center')

plt.show()


In this code, plt.subplots(2, 1, sharex=True) creates a figure with 2 subplots stacked vertically, and the sharex=True parameter ensures that both subplots share the same x-axis. You can then plot your data on each subplot as needed and customize the appearance of the plots.


What is the function of the subplot() method in matplotlib?

The subplot() method in matplotlib allows you to create multiple plots in a single figure. It takes in three arguments - the number of rows, the number of columns, and the plot number. By specifying these arguments, you can create subplots within a single figure, allowing you to compare different plots or data visualizations side by side. This method is particularly useful for creating complex and informative data visualizations.
