How to Import A C++ Dll In Matlab?

12 minutes read

To import a C++ DLL (Dynamic Link Library) in MATLAB, you need to follow these steps:

  1. Create a C++ DLL: First, create a C++ DLL with the functions you want to use in MATLAB. You can use a compiler like Visual Studio or GCC to build the DLL.
  2. Exporting Functions: Make sure the functions you want to use in MATLAB are marked for export using the appropriate compiler directives. This ensures that the functions are visible outside the DLL.
  3. Compile the DLL: Use the appropriate compiler to compile the C++ source code into a DLL. Make sure to compile it as a 32-bit or 64-bit DLL depending on your MATLAB version.
  4. Load the DLL in MATLAB: Once the DLL is compiled, you need to load it into MATLAB using the "loadlibrary" function. This function is used to load external libraries into MATLAB's memory.
  5. Define Function Prototypes: After loading the DLL, define the prototypes of the functions you want to use in MATLAB using the "libfunctions" function.
  6. Call Functions from DLL: You can now call the functions from the DLL in MATLAB by using the defined prototypes. MATLAB will internally load the corresponding functions from the DLL and execute them.
  7. Clean up: Once you are done using the DLL, unload it from MATLAB's memory using the "unloadlibrary" function.


Note: Ensure that the DLL and MATLAB are both compiled for the same architecture (32-bit or 64-bit) to avoid compatibility issues.


Make sure to refer to MATLAB's documentation for more detailed information and examples on how to import a C++ DLL in MATLAB.

Best Matlab Books to Read in 2024

1
MATLAB: An Introduction with Applications

Rating is 5 out of 5

MATLAB: An Introduction with Applications

2
MATLAB and Simulink In-Depth: Model-based Design with Simulink and Stateflow, User Interface, Scripting, Simulation, Visualization and Debugging

Rating is 4.9 out of 5

MATLAB and Simulink In-Depth: Model-based Design with Simulink and Stateflow, User Interface, Scripting, Simulation, Visualization and Debugging

3
Matlab: A Practical Introduction to Programming and Problem Solving

Rating is 4.8 out of 5

Matlab: A Practical Introduction to Programming and Problem Solving

4
MATLAB for Engineers

Rating is 4.7 out of 5

MATLAB for Engineers

5
Matlab: A Practical Introduction to Programming and Problem Solving

Rating is 4.6 out of 5

Matlab: A Practical Introduction to Programming and Problem Solving

6
MATLAB: A Practical Introduction to Programming and Problem Solving

Rating is 4.5 out of 5

MATLAB: A Practical Introduction to Programming and Problem Solving

7
MATLAB: An Introduction with Applications

Rating is 4.4 out of 5

MATLAB: An Introduction with Applications

8
MATLAB for Engineers (4th Edition)

Rating is 4.3 out of 5

MATLAB for Engineers (4th Edition)


What is the advantage of using a precompiled C++ dll in Matlab?

There are several advantages of using a precompiled C++ DLL in MATLAB:

  1. Performance: C++ code is generally faster than MATLAB code, especially for computationally intensive tasks. By compiling your C++ code into a DLL and calling it from MATLAB, you can take advantage of the optimized performance of C++.
  2. Access to existing C++ libraries: Many powerful libraries and frameworks are available in C++ for various purposes such as image processing, machine learning, numerical computations, etc. By using a precompiled C++ DLL, you can easily interface with these existing libraries from within MATLAB.
  3. Compatibility: MATLAB provides built-in support for calling functions from external DLLs. By using a precompiled C++ DLL, you can seamlessly integrate your C++ code with MATLAB, regardless of the MATLAB version or platform you are using.
  4. Code reuse: If you have already written some functionality in C++ and want to use it in MATLAB, compiling it into a DLL allows you to reuse that code without having to rewrite it in MATLAB.
  5. Confidentiality: If you have proprietary or sensitive C++ code that you'd like to protect, compiling it into a DLL provides a level of obfuscation, as MATLAB users will only have access to the DLL interface without being able to view or modify the underlying C++ code.
  6. Flexibility: MATLAB is primarily designed for rapid prototyping and high-level scripting, but it may not provide all the necessary low-level functionalities. By using a precompiled C++ DLL, you can extend the capabilities of MATLAB and have more control over the underlying code.


Overall, the advantage of using a precompiled C++ DLL in MATLAB lies in the performance improvement, access to existing libraries, compatibility, code reuse, confidentiality, and flexibility it offers.


What is the typical syntax for calling a C++ function from Matlab?

The typical syntax for calling a C++ function from MATLAB involves creating a MEX-file, which is a MATLAB executable that interfaces with C or C++ code. Here are the general steps:

  1. Write the C++ code for the function you want to call from MATLAB.
  2. Create a MEX-file in MATLAB using the MATLAB MEX compiler. This involves creating a gateway function that will be called from MATLAB and that will call your C++ function.
  3. Compile the MEX-file using the MEX command in MATLAB. This will generate a platform-specific executable that can be called from MATLAB.
  4. Call the C++ function from MATLAB using the MEX-file as a MATLAB function.


Here's an example of the general syntax for the MEX-file:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
#include "mex.h"

// Gateway function
void mexFunction(int nlhs, mxArray *plhs[], int nrhs, const mxArray *prhs[]) {
    // Check input/output arguments

    // Get input arguments from MATLAB

    // Call the C++ function

    // Set output arguments to be returned to MATLAB
}


After creating the MEX-file, you can call the C++ function from MATLAB using the following syntax:

1
output = mexFunction(input);


Where "output" is the variable to store the result and "input" is the input argument(s) to the C++ function.


Note that this is just a general overview of the process, and the specific syntax may vary depending on the inputs/outputs of your C++ function and the requirements of your application.


How to distribute a Matlab program that relies on a C++ dll?

To distribute a MATLAB program that relies on a C++ DLL, you need to follow these general steps:

  1. Package your MATLAB code and the C++ DLL into a single folder. This folder will serve as the distribution package for your program.
  2. Make sure all necessary files are included in the folder. This includes the MATLAB script/function files, the C++ DLL file, and any other dependencies or data files required for your program's execution.
  3. Include clear instructions on how to install and run the program. Ideally, provide a README file explaining the installation process and any necessary dependencies, such as specifying the MATLAB version and additional toolboxes required.
  4. Check if the target computer has the required MATLAB version and dependencies installed or provide instructions on how to install them. Ensure that the target computer also meets any system requirements specified by your MATLAB and C++ code.
  5. If your C++ DLL is platform-specific (e.g., Windows DLL), make sure to provide the appropriate version for each supported platform. You may need to compile the DLL separately for different platforms.
  6. Consider creating an installer for your program. This can simplify the installation process and ensure that all required files and dependencies are properly copied to the desired locations on the target computer.
  7. Test your distribution package on a clean system to verify that it can be installed and executed successfully. This will help ensure that all necessary components are correctly included and the program works as expected.


By properly organizing and packaging your MATLAB code, C++ DLL, dependencies, and instructions, you can distribute your program with ease and provide a seamless installation experience for your users.


How to pass arrays and matrices between Matlab and a C++ dll?

To pass arrays and matrices between MATLAB and a C++ DLL, you can use the MATLAB Engine API provided by MathWorks. This API allows you to call MATLAB functions from your C++ code and pass data between the two environments.


Here's a step-by-step guide on how to pass arrays and matrices between MATLAB and a C++ DLL:

  1. Write your MATLAB code: Start by writing the MATLAB code that defines the functions you want to call from C++. Save this code in a .m file.
1
2
3
4
function output = myFunction(input)
    % MATLAB code here
    output = ...;
end


  1. Create a C++ DLL project: In your C++ development environment (e.g., Visual Studio), create a new DLL project.
  2. Include necessary header files: Include the required header files for using the MATLAB Engine API.
1
#include "engine.h"


  1. Initialize the MATLAB Engine: Initialize the MATLAB Engine in your C++ code.
1
2
3
4
5
Engine *engine;
if (!(engine = engOpen("' '")))
{
    // Handle MATLAB Engine initialization error
}


  1. Load and evaluate the MATLAB code: Load and evaluate your MATLAB code using the engEvalString function.
1
engEvalString(engine, "run('path/to/your/code.m')");


  1. Call a MATLAB function from C++: Use the engEvalString function to call your MATLAB function with the necessary input arguments.
1
engEvalString(engine, "output = myFunction(input);");


  1. Retrieve the result: Retrieve the result from MATLAB into your C++ code using the engGetVariable function.
1
mxArray *mxOutput = engGetVariable(engine, "output");


  1. Access the data: Access the data from the mxArray structure in your C++ code.
1
double *outputData = mxGetPr(mxOutput);


  1. Pass data from C++ to MATLAB: If you want to pass data from C++ to MATLAB, create an mxArray and set its data using the desired values.
1
2
3
4
5
6
int numElements = 3;
mxArray *mxData = mxCreateDoubleMatrix(1, numElements, mxREAL);
double *data = mxGetPr(mxData);
data[0] = 1;
data[1] = 2;
data[2] = 3;


  1. Put the data into MATLAB workspace: Use the engPutVariable function to put your data into the MATLAB workspace.
1
engPutVariable(engine, "input", mxData);


  1. Clean up: Finally, clean up the allocated MATLAB data and close the MATLAB Engine.
1
2
3
mxDestroyArray(mxOutput);
mxDestroyArray(mxData);
engClose(engine);


Make sure to link your C++ DLL project with the MATLAB Engine libraries to resolve the necessary symbols.


Note: The above steps provide a general overview and you may need to modify them as per your specific requirements.
