How to Set Up And Configure Streaming Replication In PostgreSQL?

9 minutes read

Streaming replication in PostgreSQL is a method for creating a standby server that continuously keeps itself up to date with the primary server. This setup ensures high availability, fault tolerance, and data synchronization in case of failures.


Here's a step-by-step guide on setting up and configuring streaming replication in PostgreSQL:

  1. Prepare the Primary Server: Install PostgreSQL on the primary server if it's not already installed. Configure the primary server's postgresql.conf file: Set wal_level to "logical" or "replica" (replica is recommended for most scenarios). Specify a unique max_wal_senders value. Set archive_mode to "on". Set archive_command to a command that will archive WAL files (e.g., 'cp %p /path/to/archive/%f'). Create a replication user in PostgreSQL: Connect to the primary server as a superuser. Run CREATE ROLE replication_user REPLICATION LOGIN CONNECTION LIMIT 5; to create the replication user.
  2. Prepare the Standby Server: Install PostgreSQL on the standby server if it's not already installed. Configure the standby server's postgresql.conf file: Set hot_standby to "on". Set primary_conninfo to the connection string of the primary server (e.g., 'host=primary_host port=5432 user=replication_user password=replication_password'). Specify a unique recovery_target_timeline value. Create a recovery.conf file in the PostgreSQL data directory of the standby server: Set standby_mode to "on". Set primary_conninfo to the same connection string as mentioned above. Set restore_command to a command that will restore archived WAL files (e.g., 'cp /path/to/archive/%f "%p"').
  3. Synchronize the Standby Server: Copy the entire data directory from the primary server to the standby server using a tool like rsync. If you have set up WAL archiving, copy the required archived WAL files to the standby server as well.
  4. Start the Standby Server: Start the PostgreSQL service on the standby server. The standby server will enter the recovery process, connect to the primary server, and start streaming replication.


That's it! Your streaming replication setup is now complete. The standby server will continuously receive WAL data from the primary server and remain synchronized with it. In case of a primary server failure, you can promote the standby server to act as the new primary server and redirect applications to it.

Best Managed PostgreSQL Providers of 2024

1
DigitalOcean

Rating is 5 out of 5

DigitalOcean

2
Vultr

Rating is 5 out of 5

Vultr

3
AWS

Rating is 5 out of 5

AWS

4
Cloudways

Rating is 4.9 out of 5

Cloudways


What are the different methods for initiating a failover in PostgreSQL streaming replication?

There are several methods to initiate a failover in PostgreSQL streaming replication:

  1. Manual failover: This method requires manual intervention by an administrator. The administrator needs to promote a standby server to become the new primary server by executing the pg_ctl promote command.
  2. Automated failover with a dedicated tool: Various third-party tools like Patroni, repmgr, pg_auto_failover, or Stolon can automate the failover process. These tools monitor the health of the primary server and automatically promote a standby server in case of failure.
  3. Automated failover with a load balancer: A high-availability setup can employ a load balancer to monitor the primary server's health. If the primary server becomes unavailable, the load balancer can redirect traffic to a standby server, effectively initiating a failover.
  4. Virtual IP (VIP) failover: This method involves assigning a virtual IP (VIP) address to the primary server. When a failover occurs, the VIP is reassigned to a standby server, redirecting traffic to the new primary.


It's essential to carefully plan and test failover procedures to ensure a smooth transition and minimal downtime in case of a failure.


How to create a replication slot in PostgreSQL for streaming replication?

To create a replication slot in PostgreSQL for streaming replication, you can follow these steps:

  1. Connect to your PostgreSQL server using a client tool such as psql or a GUI tool like pgAdmin.
  2. Execute the following SQL command to create a replication slot: SELECT * FROM pg_create_physical_replication_slot('replication_slot_name'); Replace 'replication_slot_name' with the desired name for the replication slot.
  3. The above command will create a replication slot and return a result set with information about the newly created slot. Make a note of the pg_create_physical_replication_slot value as it will be required for future steps.
  4. Configure your PostgreSQL server to use the replication slot. Open the PostgreSQL configuration file (postgresql.conf) and update the following parameters: wal_level = replica max_wal_senders = 5 wal_keep_segments = 32 hot_standby = on primary_slot_name = 'replication_slot_name' Set wal_level to replica to enable logical decoding for replication slots. Adjust the values for max_wal_senders, wal_keep_segments, and hot_standby according to your requirements. Set primary_slot_name to the name of the replication slot created in step 2.
  5. Save the configuration file and restart the PostgreSQL server for the changes to take effect.


You have now created a replication slot in PostgreSQL for streaming replication. It can be used by a standby server to receive and apply changes from the primary server.


What are the common issues faced during PostgreSQL streaming replication setup?

Some common issues faced during PostgreSQL streaming replication setup include:

  1. Synchronization lag: There can be situations where the replica server lags behind the primary server, leading to data inconsistency. It can occur due to network issues, underpowered replica server, or high load on the primary server.
  2. Replication conflicts: If multiple changes are made to the same piece of data on the primary and replica server simultaneously, replication conflicts can arise. PostgreSQL provides conflict resolution mechanisms, but it requires manual intervention to resolve conflicts.
  3. Network connectivity issues: Reliable and stable network connectivity is crucial for streaming replication. Network interruptions or high latency can disrupt the replication process and cause replication failures.
  4. Configuration errors: Incorrect configuration of PostgreSQL streaming replication settings can lead to replication problems. Common configuration issues include incorrect IP addresses, mismatched replication slots, or improper replication methods.
  5. Disk space issues: Insufficient disk space on the replica server can prevent the replication process from completing successfully. It is important to monitor the disk usage regularly and ensure enough space for the replicated data.
  6. Authentication problems: Replication authentication errors can occur if the replica server fails to authenticate with the primary server. This can happen due to incorrect authentication settings, invalid credentials, or mismatched security configurations.
  7. Performance degradation: In some cases, streaming replication can cause performance degradation on both the primary and replica servers. Heavy replication traffic, disk I/O bottlenecks, or inadequate hardware resources can impact the overall performance of the database system.


To mitigate these issues, it is important to monitor the replication process, regularly check logs for errors, perform thorough testing before putting replication into production, and ensure proper hardware and network infrastructure.


How to handle data consistency in PostgreSQL streaming replication?

There are several ways to handle data consistency in PostgreSQL streaming replication. Here are some best practices:

  1. Use synchronous replication: By default, PostgreSQL uses asynchronous replication, which means that the primary server commits transactions before replicating them to the standby servers. However, in synchronous replication, the primary server waits for at least one standby server to confirm the transaction before committing it. This ensures that data changes are written to multiple servers before being acknowledged as committed, ensuring consistency.
  2. Monitor replication lag: Replication lag refers to the delay between changes made on the primary server and their replication to standby servers. Monitoring replication lag is crucial to identify and resolve any inconsistencies in data. You can use tools like pg_stat_replication view or third-party monitoring tools to track replication lag.
  3. Regularly check for replication errors: Replication errors can occur due to network issues, hardware failures, or other factors. It is essential to monitor and resolve any replication errors promptly. You can use PostgreSQL's Log-Shipping Alerts and Monitoring (pg_stat_replication) or third-party monitoring tools to check for replication errors.
  4. Use transactional guarantees: PostgreSQL supports transactional guarantees like ACID (Atomicity, Consistency, Isolation, Durability). Use these guarantees to ensure data consistency across the primary and standby servers. Transactions should be designed to be atomic (all or nothing), consistent (following constraints and rules), isolated (isolated from concurrent transactions), and durable (permanently saved).
  5. Perform regular data consistency checks: Set up regular data consistency checks to compare data on the primary and standby servers. You can use pg_receivewal and pg_receivexlog tools to compare the contents of WAL segments between the primary and standby servers. Additionally, you can use pg_checksums to ensure data consistency at the block level.
  6. Implement replication monitoring and alerting: Configure monitoring and alerting systems to notify administrators of any issues or inconsistencies in replication. This can include monitoring replication lag, replication errors, and overall system health.


By following these practices, you can ensure data consistency in PostgreSQL streaming replication and detect and resolve any inconsistencies promptly.
