Tutorial: Install Zabbix Server on Linode?

13 minutes read

Zabbix is an open-source monitoring software that can track and monitor the performance of various IT components in real-time. This tutorial will guide you through the process of installing Zabbix server on a Linode instance.


Before you begin, ensure that you have a Linode instance up and running and have access to it. Also, make sure you have administrative access to the Linode server.

  1. Connect to your Linode server via SSH.
  2. Update the package repository by running the command: sudo apt update
  3. Install the necessary dependencies by executing the following command: sudo apt install apache2 php php-mysql libapache2-mod-php mysql-server mysql-client
  4. Configure the MySQL server by running the command: sudo mysql_secure_installation Follow the on-screen prompts to set the desired password and secure the MySQL installation.
  5. Download the latest version of Zabbix server by visiting the Zabbix website and navigating to the Download section. Copy the link address for the desired version.
  6. Use the wget command to download the Zabbix server package. Replace with the copied link address: wget
  7. Extract the downloaded package using the tar command: tar -zxvf
  8. Move the extracted directory to the Apache web server document root: sudo cp -r /var/www/html/zabbix
  9. Grant necessary permissions to the Zabbix folder: sudo chown -R www-data:www-data /var/www/html/zabbix/
  10. Import the Zabbix database schema and initial data into MySQL by executing the following command: sudo mysql -u root -p zabbix < /var/www/html/zabbix/database/mysql/schema.sql Enter your MySQL root password when prompted.
  11. Configure the Zabbix server by copying the configuration file: sudo cp /var/www/html/zabbix/conf/zabbix.conf.php.example /var/www/html/zabbix/conf/zabbix.conf.php
  12. Edit the newly created configuration file using a text editor: sudo nano /var/www/html/zabbix/conf/zabbix.conf.php Provide your database details, including the username, password, and database name.
  13. Restart the Apache web server to apply the changes: sudo systemctl restart apache2
  14. Access the Zabbix web interface by opening a web browser and entering your Linode server's IP address or domain name, followed by /zabbix: http:///zabbix
  15. Follow the on-screen instructions to complete the Zabbix setup.


That's it! You have successfully installed Zabbix server on your Linode instance and can now start monitoring your IT infrastructure.

Best Cloud Hosting Providers of 2024

1
AWS

Rating is 5 out of 5

AWS

2
DigitalOcean

Rating is 4.9 out of 5

DigitalOcean

3
Vultr

Rating is 4.8 out of 5

Vultr

4
Cloudways

Rating is 4.6 out of 5

Cloudways


What is a Linode distribution and how to select one for Zabbix server installation?

A Linode distribution refers to the pre-installed operating system available for deployment on a Linode cloud server. Linode offers a range of distributions encompassing various Linux distributions, including Ubuntu, CentOS, Debian, Fedora, and more.


To select a Linode distribution for Zabbix server installation, the following steps can be followed:

  1. Access the Linode Manager and navigate to the Linodes tab.
  2. Choose the "Add a Linode" option and select the desired Linode plan.
  3. In the "Deploy an Image" section, choose the "Distribution" tab.
  4. Here, various operating system distributions will be listed. Select the preferred distribution suitable for your Zabbix server. It is recommended to use a reliable and supported distribution like Ubuntu LTS, CentOS, or Debian.
  5. After choosing the distribution, provide a label for the Linode and select the desired data center region.
  6. Proceed with the creation of the Linode by clicking on the "Create Linode" button.
  7. Once the Linode is created, you can access it via SSH or the Linode's Remote Access Console. Use the provided credentials to log in to the Linode.
  8. Follow the Zabbix installation documentation specific to the chosen distribution to install and configure Zabbix server.


Remember to consider the system requirements of Zabbix and compatibility with the chosen distribution to ensure smooth installation and operation of the Zabbix server.


What is a Linode StackScript and how to create one for Zabbix server?

A Linode StackScript is a script that automates the deployment and configuration of applications on a Linode server. It allows you to create and share scripts to quickly set up a pre-configured server with your desired software stack.


To create a Linode StackScript for a Zabbix server, you can follow these steps:

  1. Log in to the Linode Cloud Manager at https://cloud.linode.com.
  2. Navigate to the "StackScripts" tab in the left sidebar.
  3. Click on the "Create a StackScript" button.
  4. Provide a name and description for your StackScript.
  5. Choose the desired distribution and version for your Zabbix server.
  6. In the "Script" field, enter the script to install and configure Zabbix. Here's an example script you can use:
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
#!/bin/bash

# Update the system
apt-get update
apt-get upgrade -y

# Install prerequisites
apt-get install -y apache2 php-mysql mysql-server mysql-client php libapache2-mod-php php-mbstring php-gd php-xml php-bcmath php-ldap php-mcrypt php-mysql

# Download and extract Zabbix
wget https://repo.zabbix.com/zabbix/5.4/ubuntu/pool/main/z/zabbix-release/zabbix-release_5.4-1+focal_all.deb
dpkg -i zabbix-release_5.4-1+focal_all.deb
apt-get update
apt-get install -y zabbix-server-mysql zabbix-frontend-php zabbix-apache-conf zabbix-agent

# Create Zabbix database
mysql -uroot -p -e "create database zabbix character set utf8 collate utf8_bin;"
mysql -uroot -p -e "grant all privileges on zabbix.* to 'zabbix'@'localhost' identified by 'YourPassword';"

# Import initial schema and data
cd /usr/share/doc/zabbix-server-mysql
zcat create.sql.gz | mysql -uzabbix -p zabbix

# Configure Zabbix server
sed -i 's/# php_value date.timezone Europe\/Riga/php_value date.timezone UTC/' /etc/zabbix/apache.conf

# Restart services
systemctl restart apache2
systemctl enable zabbix-server zabbix-agent apache2


Please note that this script is for an Ubuntu-based Zabbix installation. Adjustments may be required for other distributions.

  1. Click on the "Create StackScript" button to create your StackScript.


Once your StackScript is created, you can use it to deploy Zabbix servers on Linode by selecting it during the Linode creation process. Keep in mind that you may need to modify the StackScript if Zabbix releases new versions or if you want to customize the installation further.


What is Zabbix proxy and how to configure it on Linode?

Zabbix Proxy is a component of the Zabbix monitoring system that acts as an intermediary between the Zabbix server and the monitored devices. It helps to distribute the workload and improve performance by reducing network traffic between the server and agents.


To configure Zabbix Proxy on Linode, you can follow these steps:


Step 1: Deploy a Linode Instance

  1. Login to your Linode account and click on "Create" to deploy a new Linode instance.
  2. Choose your preferred Linode plan, region, and other settings. Click on "Create" to launch the instance.


Step 2: Install Zabbix Proxy

  1. Connect to your Linode instance using SSH.
  2. Update the package lists by running the command: sudo apt update
  3. Install the Zabbix Proxy package by running: sudo apt install zabbix-proxy-sqlite3 (You can choose a different package depending on your requirements, such as zabbix-proxy-mysql or zabbix-proxy-pgsql.)
  4. During the installation, you will be asked to configure the database connection details. Provide the required information for the database.
  5. Start the Zabbix Proxy service by running: sudo systemctl start zabbix-proxy


Step 3: Configure Zabbix Proxy

  1. Open the Zabbix Proxy configuration file using a text editor: sudo nano /etc/zabbix/zabbix_proxy.conf
  2. Modify the necessary parameters, such as the Zabbix Server IP address or hostname. You may also want to customize other settings based on your requirements.
  3. Save the changes and exit the editor.
  4. Restart the Zabbix Proxy service for the changes to take effect: sudo systemctl restart zabbix-proxy


Step 4: Allow Firewall Access

  1. If you have a firewall enabled on your Linode, you need to allow access to the Zabbix Proxy ports.
  2. The default port used by Zabbix Proxy is 10051 (TCP). You can open this port using the ufw firewall utility by running: sudo ufw allow 10051


That's it! You have now successfully installed and configured Zabbix Proxy on your Linode. You can now configure your agents to use the proxy for data collection, and manage monitoring through the Zabbix server.


What is a Linode image and how to create one for Zabbix server installation?

A Linode image is a pre-configured disk image that contains all the necessary files and settings required to set up a specific software or server environment. It helps simplify the process of deploying and setting up servers by providing a pre-built starting point.


To create a Linode image for Zabbix server installation, you can follow these steps:

  1. Set up a Linode instance: Start by creating a new Linode instance and selecting the desired specifications for your server.
  2. Install the operating system: Choose an operating system that is compatible with Zabbix server installation. Ubuntu or CentOS are commonly used choices. Install the operating system on your Linode instance.
  3. Install the required dependencies: Zabbix server has certain dependencies that need to be installed. These typically include packages like Apache, PHP, MySQL, and others. Install these dependencies on your Linode instance using package managers like apt or yum.
  4. Install and configure Zabbix server: Download and install the Zabbix server package based on your operating system. Follow the official Zabbix documentation for detailed instructions on the installation process. Configure the Zabbix server by editing its configuration files to meet your requirements.
  5. Secure the server: Configure security measures, such as firewall rules, to protect your Zabbix server. Ensure that only necessary ports and services are exposed.
  6. Test and validate: Test the Zabbix server installation to ensure it is functioning correctly. Verify that you can access the Zabbix web interface and that it can monitor systems as expected.
  7. Create a Linode image: Once you have completed the Zabbix server setup and configuration, power off your Linode instance. From the Linode Manager, navigate to the "Images" tab and select "Create Image." Follow the prompts to create an image of your Linode instance.


After the image is created, you can use it to deploy new Linode instances with Zabbix server pre-installed, reducing the setup time and effort required for future deployments.


How to navigate the Linode dashboard?

To navigate the Linode dashboard, follow these steps:

  1. Login: Go to the Linode website and click on the "Sign In" button located at the top right corner. Enter your credentials and click "Sign In" to access your account.
  2. Dashboard Overview: After logging in, you will land on the dashboard page. This page provides an overview of your Linodes, services, billing, support, and other important information.
  3. Left Sidebar: The left sidebar contains various sections including "Dashboard", "Linodes", "Volumes", "NodeBalancers", "Domains", "Networking", "Marketplace", "StackScripts", "Longview", "Kubernetes", "Account", and "Apps & Services". Click on any section to access its related settings or features.
  4. Linodes: Click on the "Linodes" section in the sidebar to manage your Linodes. Here, you can create new Linodes, view and configure existing Linodes, monitor resource usage, access console, manage remote access, perform backups, and more.
  5. Volumes: In the "Volumes" section, you can create and manage block storage volumes that can be attached to your Linodes. You can create, resize, delete, and attach volumes to Linodes as necessary.
  6. NodeBalancers: If you have NodeBalancers, go to the "NodeBalancers" section to manage and configure them. NodeBalancers are used for load balancing across multiple Linodes to improve your application's availability and reliability.
  7. Domains: In the "Domains" section, you can manage your domain names associated with Linode. You can add, edit, delete, and configure DNS records for your domains.
  8. Networking: This section allows you to manage networking-related settings like floating IPs, IP sharing, and IP reservations.
  9. Marketplace: The "Marketplace" section provides a catalog of pre-configured applications and stacks that can be deployed on your Linodes with just a few clicks.
  10. StackScripts: In the "StackScripts" section, you can create and manage custom scripts that can be used to automatically deploy and configure software on your Linodes.
  11. Longview: "Longview" provides system statistics and monitoring for your Linodes. You can install the Longview agent on your Linodes and then view resource utilization, graphs, and historical data in this section.
  12. Account: The "Account" section allows you to manage your account settings, including user management, security settings, billing information, and other account details.
  13. Apps & Services: In this section, you can discover and integrate third-party applications and services with your Linode account.


By utilizing these sections and features in the Linode dashboard, you can effectively manage and configure your Linode infrastructure.


What is the Linode API and how to use it for Zabbix server installation?

The Linode API is an application programming interface provided by Linode, a cloud hosting provider. It allows users to programmatically manage their Linode resources, such as creating and deleting servers, managing DNS records, and more.


To use the Linode API for a Zabbix server installation, you would typically follow these steps:

  1. Obtain Linode API credentials: You need to generate an API key from the Linode Cloud Manager. This key will be used for authenticating your API requests.
  2. Set up the Linode server: Using the Linode API, you can create a new Linode server or choose an existing one for your Zabbix installation. This may include selecting the server's location, type, and size.
  3. Configure the server: Use the Linode API to configure the server with the necessary networking settings, such as setting up static IP addresses, configuring DNS records, and firewall rules.
  4. Install Zabbix server: Once the server is set up, you can use the Linode API to provision the server with the required software packages and dependencies for Zabbix. This can be done using configuration management tools like Ansible, Chef, or Puppet, which can interact with the Linode API on your behalf.
  5. Monitor and manage the Zabbix installation: After the Zabbix server is installed, you can use the Linode API to manage and monitor the server's resources, such as CPU usage, memory, disk space, and network bandwidth. This can be useful for scaling up or down, performing backups, or applying security patches.


Note that the exact implementation details may vary depending on your specific requirements, but the Linode API provides a flexible and programmable interface for managing your Zabbix server installation on Linode.
