How to Install Zabbix Server on VPS?

10 minutes read

To install Zabbix server on a VPS (Virtual Private Server), follow these steps:

  1. Connect to your VPS: Use SSH (Secure Shell) or any other remote access method to connect to your VPS using a terminal.
  2. Update the system: Before installing any software, update your VPS to ensure it has the latest packages. Run the following command: sudo apt update && sudo apt upgrade
  3. Install necessary dependencies: Zabbix server requires some dependencies to be installed. Install them by running the following command: sudo apt install apache2 php libapache2-mod-php7.2 mysql-server mysql-client libmysqlclient-dev
  4. Configure MySQL: During the installation process, the MySQL server will prompt you to set a root password. Set a secure password and remember it as you will need it later.
  5. Create a MySQL database for Zabbix: After configuring MySQL, login as the root user and create a database for Zabbix. Use the following commands: sudo mysql -u root -p CREATE DATABASE zabbix character set utf8 collate utf8_bin; GRANT ALL PRIVILEGES ON zabbix.* TO 'zabbix'@'localhost' IDENTIFIED BY 'zabbixpassword'; FLUSH PRIVILEGES; quit Replace 'zabbix' and 'zabbixpassword' with your desired database username and password.
  6. Download Zabbix repository: Fetch the Zabbix repository by running the following commands: wget https://repo.zabbix.com/zabbix/5.4/ubuntu/pool/main/z/zabbix-release/zabbix-release_5.4-1+ubuntu20.04_all.deb sudo dpkg -i zabbix-release_5.4-1+ubuntu20.04_all.deb
  7. Install Zabbix server and frontend: Now, install the Zabbix server and its frontend with the following command: sudo apt update sudo apt install zabbix-server-mysql zabbix-frontend-php
  8. Import the initial database schema: Invoke the following command to import the initial Zabbix database schema: sudo zcat /usr/share/doc/zabbix-server-mysql*/create.sql.gz | sudo mysql -uzabbix -p zabbix
  9. Configure Zabbix server: Edit the Zabbix server configuration file using a text editor like nano: sudo nano /etc/zabbix/zabbix_server.conf Adjust the following parameters: DBHost=localhost DBName=zabbix DBUser=zabbix DBPassword=zabbixpassword Replace 'zabbixpassword' if you used a different password earlier.
  10. Configure PHP: Edit the PHP configuration file used by Apache: sudo nano /etc/zabbix/apache.conf Edit the value of 'php_value date.timezone' to reflect your timezone (e.g., 'Europe/London').
  11. Restart services: Restart Apache and Zabbix services to apply the changes: sudo systemctl restart apache2 sudo systemctl restart zabbix-server
  12. Access the Zabbix frontend: Open a web browser and enter the IP address of your VPS followed by '/zabbix' in the address bar. You will be directed to the Zabbix frontend installation wizard.
  13. Follow the Zabbix frontend installation wizard: Provide the necessary details such as database connection information and Zabbix server hostname or IP. Also, set an administrative username and password.
  14. Complete the installation: Once the installation wizard is finished, you will be redirected to the Zabbix login page. Enter your credentials to access the Zabbix server.


Congratulations! You have successfully installed Zabbix server on your VPS.

Best Cloud Hosting Providers of June 2024

1
AWS

Rating is 5 out of 5

AWS

2
DigitalOcean

Rating is 4.9 out of 5

DigitalOcean

3
Vultr

Rating is 4.8 out of 5

Vultr

4
Cloudways

Rating is 4.6 out of 5

Cloudways


What are the recommended plugins for Zabbix server?

There are several recommended plugins for Zabbix server that can extend its functionality. Some of these plugins include:

  1. Grafana-Zabbix: This plugin integrates Zabbix with Grafana, allowing you to create advanced and visually appealing dashboards.
  2. Zabbix SNMP Trap Receiver: This plugin enables Zabbix to receive and process SNMP trap messages from SNMP devices.
  3. Zabbix-Java Gateway: This plugin provides support for monitoring Java applications using JMX (Java Management Extensions).
  4. Zabbix-Data-Manager: This plugin allows for easy management and manipulation of Zabbix data, including data importing and exporting.
  5. Zabbix-DB-Agent: This plugin offers improved database monitoring capabilities, supporting various database systems.
  6. Zabbix Mapping Import: This plugin allows you to import network maps created using external tools into Zabbix.
  7. Zabbix-Map-Updater: This plugin automatically updates network maps in Zabbix with new hosts and other changes.
  8. Zabbix-Ticketing: This plugin integrates Zabbix with popular ticketing systems like JIRA and ServiceNow, creating tickets for identified issues or events in Zabbix.


It is important to note that the availability and compatibility of these plugins may vary depending on the Zabbix server version you are using.


What is the Zabbix template and how to use it?

Zabbix template is a pre-defined configuration file that contains settings, items, triggers, and graphs for monitoring a specific device, service, or application. It provides an easy and convenient way to monitor various aspects of a system without having to manually configure each individual component.


To use a Zabbix template, follow these steps:

  1. Download the desired template from the Zabbix website or create your own template using the Zabbix web interface.
  2. Log in to your Zabbix web interface and navigate to the "Configuration" tab.
  3. Select "Templates" from the sidebar and click on the "Create template" button.
  4. Provide a name and optional description for the new template.
  5. Under the "Items" tab, import the template XML file by clicking on the "Import" button. Browse and select the template file, then click "Import" again to confirm.
  6. After importing, review the items and make any necessary modifications to fit your requirements.
  7. Next, go to the "Triggers" tab and review the imported triggers. Again, modify them if needed.
  8. Navigate to the "Screens" and "Graphs" tabs to import any associated screens or graphs related to the template.
  9. Once all modifications are made, click on the "Update" button to save the template.
  10. Assign the template to the appropriate host(s) by going to the "Hosts" tab, selecting the host, clicking "Templates", and linking the desired template to the host.


By following these steps, you can utilize a Zabbix template to easily configure and monitor specific devices or services in your Zabbix monitoring system.


What is the purpose of Zabbix agents in server monitoring?

The purpose of Zabbix agents in server monitoring is to collect data from the target server and send it to the Zabbix server for further analysis and monitoring.


The agents installed on the target servers actively monitor various system parameters such as CPU usage, memory utilization, network statistics, and disk space. They are responsible for gathering this data at regular intervals and forwarding it to the Zabbix server for processing.


Zabbix agents also play a crucial role in executing remote commands on the monitored servers, allowing administrators to perform tasks like restarting services, managing configurations, or troubleshooting issues remotely.


Overall, Zabbix agents enable comprehensive monitoring and management of various server metrics, enabling administrators to identify potential issues and take necessary actions proactively.


How to set up alerts and notifications in Zabbix server?

To set up alerts and notifications in Zabbix server, follow these steps:

  1. Create a media type: Go to "Administration" > "Media types" and click on "Create media type". Provide a name, type (e.g., Email), and configure the necessary parameters (e.g., SMTP server and email address). Save the media type.
  2. Create a user: Go to "Administration" > "Users" and click on "Create user". Enter the user details and assign them to a user group. In the "Media" tab, add the previously created media type and configure the necessary parameters (e.g., email address). Save the user.
  3. Configure action: Go to "Configuration" > "Actions" and click on "Create action". Give the action a name and configure the conditions (e.g., trigger severity and event source). In the "Operations" tab, click on "New" to add an operation. Choose the previously created user, select the media type, and set the message subject and body. Save the action.
  4. Set up triggers: Go to "Configuration" > "Hosts" and select a host. Find the trigger you want to configure notifications for and click on "configure". In the "Actions" tab, click on "Add" to associate the previously created action with the trigger. Save the changes.
  5. Enable notifications: Go to "Administration" > "Media types" and click on the created media type (e.g., Email). Make sure it is enabled.


Now, when the configured trigger condition is met, Zabbix server will send a notification to the specified email address.


How to integrate Zabbix server with external applications?

To integrate Zabbix server with external applications, you can use the following methods:

  1. Using Zabbix API: Zabbix provides a robust API that allows you to interact with the server programmatically. You can use this API to integrate Zabbix with other applications by making API calls to retrieve or update data. This can be done using various programming languages such as Python, PHP, or Ruby.
  2. Using Zabbix Webhooks: Zabbix supports webhooks, which are HTTP callbacks triggered by specific events in Zabbix. You can configure Zabbix to send notifications or trigger actions via webhooks, allowing you to integrate it with any system that can receive and process HTTP requests.
  3. Using Zabbix Plugins: Zabbix supports plugins that extend its functionality and allow integration with external systems. You can develop custom plugins or use existing ones to integrate Zabbix with applications such as Slack, Jira, or Grafana.
  4. Using Zabbix Database: Zabbix stores its data in a relational database (MySQL, PostgreSQL, etc.). You can directly access the database to extract or update data as needed. However, this method requires knowledge of the Zabbix database structure and careful handling of the data to avoid integrity issues.
  5. Using Zabbix Scripts: Zabbix allows you to execute custom scripts as part of its monitoring and alerting process. You can write scripts that interact with external applications or systems and configure Zabbix to execute them when specific conditions are met.


Overall, the choice of integration method depends on your specific requirements and the capabilities of the external applications you want to integrate with Zabbix.
